• 600W 78000lm ATEX Zone 1 Zone 2 Explosion Proof LED Flood Light for Hazardous Areas
600W 78000lm ATEX Zone 1 Zone 2 Explosion Proof LED Flood Light for Hazardous Areas

600W 78000lm ATEX Zone 1 Zone 2 Explosion Proof LED Flood Light for Hazardous Areas

جزئیات محصول:

محل منبع: گوانگدونگ، چین
نام تجاری: Fins board, BOCAQ
گواهی: CE,ROHS,FCC,PSE,CCC,ATEX, ISO9001,BSCI
شماره مدل: EPFL-600W-Z1

پرداخت:

مقدار حداقل تعداد سفارش: 10 عدد
قیمت: قابل مذاکره
جزئیات بسته بندی: بسته جعبه + حباب یا به صورت سفارشی
زمان تحویل: 10-15 روز یا تأیید
شرایط پرداخت: T/T، وسترن یونیون
قابلیت ارائه: 5000 عدد در ماه
بهترین قیمت مخاطب

اطلاعات تکمیلی

قدرت: 600 وات شار نورانی: 78000 لیتر
اثربخشی: 130lm/W دمای رنگ: ۵۰۰۰K (سفید سرد)
زاویه پرتو: 120 درجه ولتاژ ورودی: AC 100-277V 50/60Hz
تراشه LED: Bridgelux SMD 3030 رتبه بندی IP: IP66
مصالح مسکن: آلومینیوم دایکاست ADC12 مواد لنز: شیشه سکوریت 5 میلی متر
دمای عملیاتی: -40 تا +60 درجه سانتی گراد گزینه های نصب: براکت قابل تنظیم، پایه پایه، پایه سقفی
گواهی: ATEX II 2G Ex d IIC T6 Gb طول عمر: ≥50000 ساعت L70
گارانتی: 5 سال
برجسته کردن:

600W Explosion Proof Light

,

ATEX Zone 1 LED Floodlight

,

Hazardous Area Industrial Lighting

توضیحات محصول

600W Explosion Proof LED Flood Light ATEX Zone 1 Zone 2 Hazardous Area 78000lm IP66 Die-Cast Aluminum Lighting
600W Explosion Proof LED Flood Light - ATEX Certified Zone 1 Hazardous Area Lighting

The EPFL-600W-Z1 is a high-power 600W explosion proof LED flood light engineered for demanding industrial environments requiring ATEX Zone 1 and Zone 2 certification. With an outstanding 78000lm luminous output and 130lm/W efficacy, this floodlight delivers exceptional illumination while maintaining the strictest safety standards for hazardous locations. A direct replacement for traditional 2000W HID/HPS floodlights with over 65% energy savings.

Key Features
  • 600W High Power Output - 78000lm total luminous flux with 130lm/W efficacy, replacing 2000W HID equivalents
  • ATEX Certified - ATEX II 2G Ex d IIC T6 Gb for Zone 1, Zone 2 gas and Zone 21, Zone 22 dust atmospheres
  • Robust Die-Cast Aluminum Housing - ADC12 aluminum alloy with anti-corrosion powder coating for long-term outdoor durability
  • IP66 Weatherproof - Fully sealed against dust ingress and powerful water jets, suitable for the harshest environments
  • 5mm Tempered Glass Lens - High-transmittance glass with IK08 impact resistance rating
  • Bridgelux SMD 3030 LEDs - Premium LED chips delivering stable 5000K cool white light
  • Wide 120° Beam Angle - Optimal light distribution for large-area coverage in refineries, chemical plants, and offshore platforms
  • Universal Voltage Input - AC 100-277V 50/60Hz compatible with global electrical systems
  • Multiple Mounting Options - Adjustable bracket, pole mount, and ceiling mount configurations included
  • 5-Year Warranty - Backed by ≥50,000 hours L70 lifespan testing
Applications

Ideal for ATEX Zone 1 and Zone 2 classified areas including:

  • Oil refineries and petrochemical processing plants
  • Offshore drilling platforms and FPSO vessels
  • Chemical storage warehouses and mixing facilities
  • Gas compressor stations and LNG terminals
  • Paint spray booths and solvent handling areas
  • Grain silos and flour mills (dust explosive atmospheres)
  • Coal mining preparation plants
Technical Specifications
Model Number EPFL-600W-Z1
Power Consumption 600W
Luminous Flux 78000lm
Efficacy 130lm/W
Color Temperature 5000K (Cool White)
Beam Angle 120°
Input Voltage AC 100-277V 50/60Hz
LED Chip Bridgelux SMD 3030
IP Rating IP66
Housing Material Die-Cast Aluminum ADC12
Lens Tempered Glass 5mm
Operating Temperature -40°C to +60°C
Mounting Adjustable Bracket / Pole Mount / Ceiling Mount
Certification ATEX II 2G Ex d IIC T6 Gb
Lifespan ≥50,000 Hours L70
Warranty 5 Years
Why Choose ECER 600W Explosion Proof Flood Light?

As a leading manufacturer of hazardous area lighting solutions, ECER delivers explosion proof LED flood lights that combine cutting-edge LED technology with rigorous safety engineering. The EPFL-600W-Z1 is our flagship high-power model, designed for applications demanding maximum lumen output in ATEX classified environments. Each unit undergoes 100% factory testing including pressure testing of the explosion-proof enclosure and photometric verification.

For bulk orders, OEM/ODM customization, or technical inquiries, please contact our sales team.
