600W LED Explosion Proof Flood Light 90° Flange Mount Structural Platform Yellow ATEX IIB T6 IP65 RFEPL8280 Lighting
جزئیات محصول:
| محل منبع: | گوانگدونگ، چین |
| نام تجاری: | ECER |
| گواهی: | ATEX Ex db mb IIB T6, CE, ROHS, CCC |
| شماره مدل: | RFEPL8280-600W-FL90 |
پرداخت:
| مقدار حداقل تعداد سفارش: | 10 عدد |
|---|---|
| قیمت: | قابل مذاکره |
| جزئیات بسته بندی: | بسته جعبه + حباب یا به صورت سفارشی |
| زمان تحویل: | 10-15 روز یا تأیید |
| شرایط پرداخت: | T/T، وسترن یونیون |
| قابلیت ارائه: | 5000 عدد در ماه |
|
اطلاعات تکمیلی |
|||
| قدرت: | 600 وات | بهره وری نور: | 100-120 لیتر/w |
|---|---|---|---|
| تراشه LED: | LUMILEDS SMD (LM-80) | زاویه پرتو: | 90 درجه |
| دمای رنگ: | 5000K | رتبه بندی IP: | IP65 |
| علامت ضد انفجار: | Ex db mb IIB T6 - IP65 - WF2 | حفاظت در برابر صاعقه: | 6 کیلو ولت |
| مواد: | آلومینیوم ADC12 + شیشه سکوریت | پایان: | زرد |
| گواهی: | ATEX, CE, ROHS, CCC | طول عمر: | 50000 ساعت |
| دمای عملیاتی: | -40 تا +60 درجه سانتی گراد | ||
| برجسته کردن: | 600W explosion proof LED flood light,ATEX IIB T6 explosion proof lighting,IP65 flange mount flood light |
||
توضیحات محصول
600W LED Explosion Proof Flood Light - 90° Flange Mount Structural Platform Yellow RFEPL8280 Series
The RFEPL8280-600W-FL90 is a 600W LED explosion proof flood light from the RFEPL8280 series, delivering 78000lm luminous flux with 130lm/W efficiency. ATEX Ex db mb IIB T6 certified with IP65 WF2 protection, this Yellow finish floodlight features LUMILEDS SMD chip technology (LM-80 tested), 6KV lightning protection, and all-stainless-steel hardware passing 500-hour salt spray testing.
Key Features
- LUMILEDS SMD Technology - LM-80 tested premium LED chips delivering 130lm/W with CRI ≥80 and 50,000-hour L70 lifespan
- ATEX Ex db mb IIB T6 Certified - Zone 1/Zone 2 gas and Zone 21/Zone 22 dust hazardous atmospheres, temperature classes T1-T6
- 90° Beam Configuration - 90° Flange Mount Wide Flood for precise light distribution
- Yellow Paint Finish - Durable powder coat finish with 500-hour salt spray certification on all stainless steel hardware
- Die-Cast Fin Heat Dissipation - Advanced aluminum substrate thermal management for reliable 600W continuous operation
- 6KV Lightning Protection - Built-in surge suppression for exposed outdoor industrial installations
- 180° Adjustable Bracket - Flexible angle adjustment with six mounting configurations available
- IP65 Waterproof WF2 - Sealed against dust and water jets with corrosion-resistant design
- Universal AC 100-277V - Power factor ≥0.95, compatible with global electrical systems
- CE, ROHS, CCC Certified - Full international compliance for global deployment
Applications
Suitable for Flange-mounted wide flood for structural columns and vessel platforms in large refineries:
- Oil extraction, refining and petrochemical processing
- Offshore platforms, FPSOs and drilling rigs
- Chemical storage, mixing and manufacturing facilities
- Electric power generation and distribution stations
- Military and defense hazardous installations
Technical Specifications
| Model Number | RFEPL8280-600W-FL90 |
|---|---|
| Item No. | RFEPL8280 |
| Power | 600W |
| Light Efficiency | 100-120lm/W |
| LED Chip | LUMILEDS SMD (LM-80) |
| Beam Angle | 90° |
| CRI | ≥80 |
| Explosion-Proof Mark | Ex db mb IIB T6 - IP65 - WF2 |
| Lightning Protection | 6KV |
| Material | Aluminum ADC12 + Tempered Glass |
| Finish | Yellow |
| Mounting | Ceiling / Boom / Bracket / Wall / Flange / Guardrail |
| Certification | ATEX, CE, ROHS, CCC |
| Lifetime | 50,000 Hours |
| Operating Temperature | -40°C to +60°C |
The RFEPL8280 series delivers industrial-grade hazardous area illumination with LUMILEDS LED efficiency and ATEX-certified safety. Every unit is factory-tested for explosion-proof integrity and photometric performance.
For bulk pricing, OEM customization, or technical consultation, please contact our sales team.
